Transform Your Construction Site with the SEMIX Mobile 120S4: The Ultimate Mobile Concrete Batching Plant

In today's fast-paced construction industry, project managers and technical professionals face mounting pressure to deliver high-quality concrete mixtures on schedule, without compromising on durability or operational flexibility. Traditional stationary batching plants often leave you tied to a single location, increasing costs for material transport and setup. How can you achieve both mobility and the robustness of a stationary plant? The answer lies in the SEMIX Mobile 120S4, the industry-leading mobile concrete batching plant built for efficiency, reliability, and ease of operation.

Why the SEMIX Mobile 120S4 Meets Your Every Need

Whether you're operating on a sprawling multi-site project or tackling tight urban builds, the SEMIX Mobile 120S4 is engineered to keep your operations agile without sacrificing performance:

• Patented Inline Aggregate Storage Silos: Load all silos with just one ramp—no pre-feeding conveyor required. This innovative design saves time, space, and labor.
• Stationary Plant Robustness on a Mobile Chassis: The heavy-duty steel frame brings unparalleled stability, closely mirroring stationary plant performance, even in rigorous conditions.
• Rapid Deployment & Easy Relocation: Move the entire batching plant anywhere on-site in minutes, reducing downtime and allowing you to adapt to changing project layouts.
• High-Precision Weighing Systems: Cement, water, and admixture load-cells maintain ingredient accuracy to the kilogram, ensuring each batch meets exacting quality standards.

Patented Design for Inline Aggregate Storage Silos

SEMIX’s S4 series revolutionizes the loading process. By integrating inline silos, the Mobile 120S4 eliminates the need for an upstream conveyor belt, drastically reducing setup complexity and maintenance costs. You gain:

• Faster feed rates
• Lower energy consumption
• Reduced wear on mechanical components

Steel Chassis: Mobility Meets Durability

With a rugged steel chassis designed for heavy-duty use, the SEMIX Mobile 120S4 withstands the harshest jobsite conditions. You'll experience:

• Enhanced Stability: No swaying or structural fatigue during operation.
• Longevity: Built to outlast portable solutions, saving you on replacement costs.
• Ease of Transport: Compatible with standard site vehicles and quick-attach systems.

Unmatched Mixing Performance with SEMIX Concrete Mixers

At the heart of the SEMIX Mobile 120S4 lies your choice of high-capacity mixers:

• 3.00 m³ Single Shaft Mixer – Ideal for projects seeking consistent mixing with lower energy consumption.
• 3.33 m³ Twin Shaft Mixer – Perfect for high-volume requirements. Achieve up to 3.33 m³ of compacted concrete per batch with a 5.0 m³ dry volume reservoir and a powerful 2 x 55 kW motor configuration.

Superior Wear Resistance with Ni-Hard 4 Alloy

All mixing and stripping blades, along with internal wearing plates, utilize Ni-Hard 4—a chrome-nickel alloy boasting a tensile strength of up to 1,200 MPa. Benefits include:

• Exceptional Abrasion Resistance: Handles large aggregate sizes (up to 75 mm) without premature wear.
• Thermal Stability: Low thermal expansion ensures dimensional integrity under high-temperature operations.
• Extended Service Life: Less downtime for blade replacements leads to continuous productivity.

Advanced Components for Maximum Efficiency

Every detail of the SEMIX Mobile 120S4 is optimized for performance and reliability:

Automatic Lubrication System

• 8-Point SKF-Lincoln System: Ensures critical bearings and pivot points stay lubricated for smooth operation.
• Reduced Maintenance: Automated oil delivery cuts manual grease checks by up to 80%.

Precise Weighing Hoppers

• Cement Weighing: 1,600 kg capacity with 3 load-cells
• Water Weighing: 1,000 kg capacity with 2 load-cells
• Additive Weighing: 1-2 x 20 L capacity with 1 load-cell
• High Accuracy: Guarantee mix consistency and reduce waste.

Robust Aggregate Storage & Conveyance

• Storage Bins: 4 linear bins of 15–25 m³ each (60–100 m³ total), equipped with trapezoidal reinforced covers and extra steel reinforcement.
• Discharging Gates: 2 per bin (8 total) for controlled flow of materials.
• Weighing Conveyors: EP 125 belts, 22–30 kW motors, WAM-OLI vibrators, emergency stop and pull-rope switches.
• Transfer Conveyor: Semi-closed steel sheet cover, 30 kW motor, and safety features aligned with industry-best practices.

Shopping Guide: Choose the Right Mobile Concrete Batching Plant

As you evaluate options for on-site concrete batching, keep in mind these critical factors:

• Output Capacity: Match mixer volume and batch frequency with project demands.
• Mobility Requirements: Ensure the plant can relocate easily across uneven terrain.
• Component Quality: Look for premium materials like Ni-Hard alloys and SKF lubrication systems to reduce lifecycle costs.
• Automation & Control: Opt for systems with advanced weighing, PLC controls, and remote monitoring capabilities.
• Service & Support: Choose a manufacturer with global presence, fast spare-part delivery, and technical training programs.

Installation & Commissioning Tips

To get the most from your SEMIX Mobile 120S4:

• Plan site layout to minimize conveyor lengths.
• Ensure electrical and water connections meet plant specifications.
• Schedule operator training and preventative maintenance plans before full-scale operation.

Unlock Productivity with SEMIX Mobile 120S4

From high-rise developments to remote infrastructure projects, the SEMIX Mobile 120S4 provides the flexibility, durability, and precision you need to stay ahead of schedule and under budget. Experience the combined power of stationary plant performance and on-site mobility today.

Discover the SEMIX Mobile 120S4 and Get a Customized Quote Now
